PCB डिजाइनबाट जन उत्पादनमा, फ्यानवे द्रुत-टर्न PCB उत्पादन सेवाहरू प्रदान गर्दछ तपाईंको विविध प्रोजेक्ट आवश्यकताहरू सम्बोधन गर्न र तपाईंको समय-देखि-मार्केटको गति बढाउन।
24-hour quick turn RF prototypes, in-house 110GHz vector network analyzer testing.
15,000㎡facility with Class 1000 RF cleanrooms, automated AOI with 15μm resolution.
Our advanced equipment, quick delivery, and cost effective allows us to meet your diverse demands.
ISO 13485 certified, UL 94V-0 flame rated materials
✓ Frequency Range: DC to 110GHz
✓ Materials: Rogers, Taconic, Arlon, PTFE, Ceramic filled.
✓ Layer Count: 1 to 32 Layers.
✓ Tolerances: ±1.5mil line width, ±0.5mil dielectric thickness.
✓ Surface Finishes: ENEPIG, Immersion Silver, Gold Finger.
✓ Special Features: Embedded passives, via in pad, hybrid constructions.
Low Loss Material
Dk control within ±0.05 across panel.
Laser ablation for ultra-precise RF shielding cavities
Automated Df monitoring during lamination (0.0015-0.003 typical)
Impedance Control
±5% impedance tolerance up to 40GHz
3D electromagnetic field simulation for complex RF transitions
Thermal Management
Metal-core (IMS) and active cooling solutions
CTE matched substrates for harsh environments
Telecommunication: 5G/6G base stations.
Defense: Phased-array radar PCBs with >64 layers and via-in-pad technology.
Aerospace: Satellite RF.
Medical: High-resolution MRI coils with EMI shielding to IEC standards.
